Description
The Abertax® GRS valve has been specially developed for installation in Gel and AGM batteries. The GRS valve releases the pressure build-up of gas in a battery, and also prevents air from entering into the cell which may ruin the plates. This patented device incorporates a unique diaphragm system which makes this valve a completely reliable, safe and extremely efficient unit. The device, due to its exceptional design, lends itself to additional specific customer requirements.
Product and Safety Features
- Patented Design
- Choice of specially selected materials to withstand the harsh battery environment, high temperatures and corrosive gases.
- The valve prevents air from entering – even if there is a negative pressure in the battery cell – for example during recombination.
- Excellent gas flow release (patented feature – making this valve superior to others on the market).
- Not affected by normal high or low operating temperatures.
- Acts as a fire barrier to the inside of the cell.
- All Abertax® GRS supplied are 100% individually function tested and guaranteed.
- No welding features incorporated in the valve construction – eliminating any possible distortion, warping, shrinkage, leakage etc. – which negatively affect performance.
- All individual parts are produced in-house – thus providing strict and excellent quality control on each individual part before and after assembly.
- Accurate opening and closing pressure parameters according to customer demand (patented).
Variants
The GRS comes in several variants designed to target any desired application. View our brochure to learn more.
GRS M18 Central Degassing for AGM
GRS M18S Central Degassing
GRS M18S
GRS M27
GRS Bayonet
GRS Push-In
Specifications
| Standard Valve Opening Pressures: | 110mbar to 165mbar For more pressure ranges, see Product Brochure. |
| Nominal Closing Pressure: | > 85mbar |
| Operating Temperature Range: | -30°C to +80°C |
| Tightening Torque: | 70Ncm to 110Ncm |
